High Brightness P6 Super Slim Aluminum Led Cabinet 768mm X 768mm Smd3528

Name: High Brightness P6 Super Slim Aluminum Led Cabinet 768mm X 768mm Smd3528
Brand: SRYLED
Price: 650 USD

Quality High Brightness P6 Super Slim Aluminum Led Cabinet 768mm X 768mm Smd3528 for sale

Brand Name : SRYLED

Model Number : SRYLED - IFC - P6

Certification : CE, LVD, RoHS

Place of Origin : Shenzhen, China

MOQ : 1sqm

Price : US$ 650 - 750 / Square Meter

Payment Terms : T/T, PayPal, Western Union

Supply Ability : 1,000 Square Meter per Month

Delivery Time : 10 - 12 Work Days

Packaging Details : Wooden Case (wooden case size depend on cabinet quantity)

Pixel Pitch : 6mm

Color Configuration : 1R1G1B 3in1

LED Encapsulation : SMD3528

Cabinet Size : 768mm x 768mm

Cabinet Weight : 18kg

Cabinet Color : Black(Optional)

Cabinet Material : Stainless Steel

Warranty : 2 Full Years

Contact Now

High Brightness P6 Super Slim Aluminum Led Cabinet 768mm X 768mm Smd3528

Decription:

P6 Indoor Full Color 768mm x 768mm LED Display Cabinet, Black Stainless Steel LED Cabinet. Super slim cabinet design makes the cabinet more beautiful.

Features:

1. High flatness precision: with die-cast aluminum technology, the tolerance of cabinet and module are controlled within 0.1mm, screen flatness and split joint gap are controlled within 0.3mm.

2. High color consistency and contrast: The module mask is designed with rubber material, no screws needed, high color contract and flatness.

3. High heat stability: great heat dissipation design, with heat conduction rubber, PCB aluminum casing and dissipation system.

4. High-end display effect: high refresh, high gray scale, high color contrast, and high quality picture effect.

5. High structure performance: easy connection of each components, modules and HUB card without flat cables, modules and systems without power cable.

6. Easy maintenance: each module can be dismantled and installed without taking out power, system card and any other components.

7. Beautiful appearance: humanized arc handle design, it's a perfect show of technology and art.

Specification:

Pixel Pitch	6mm
Pixel Density	27,777dots/sqm
Tube Chip Color	Full Color
Color Configuration	1R1G1B 3in1
LED Encapsulation	SMD3528
Module Size	192mm x 192mm
Module Resolution	32dots x 32dots
Cabinet Size	768mm x 768mm
Cabinet Resolution	128dots x 128dots
Cabinet Weight	18kg
Drive Duty	1/16 Constant Current
Brightness	>1,500nits
Viewing Distance	6m - 60m
Viewing Angle	H: 120°, V: 120°
Refresh Rate	2,000HZ
Frame Rate	120frame/sec
Grey Grade	256levels of Each Color
Color Grade	16.7M
Power Input	5V - 40A, AC110V/ 220V/ 50HZ
Max Power Consumption	420W/sqm
Ave. Power Consumption	120W/sqm
Storage Temperature	-40℃ - +80℃
Working Temperature	-20℃ - +60℃
Blind Spot Rate	<1/10,000
MTBF	>10,000 Hours
Life Span	>100,000 Hours
Operating Humidity	10% - 95%
Control System	Synchronous, Asynchronous
Operating System	Win 98, Win2000, XP, 07.etc
Input Source	All Format (AVI, MPEG,VOB, RM, etc)
Certificate	CE, LVD, RoHS

Application:

Widely using for music concert, theater, stadium, showroom, stage, monitoring room and etc.

Pictures:

High Brightness P6 Super Slim Aluminum Led Cabinet 768mm X 768mm Smd3528

Competitive Advantages:

1. Vivid and brilliant color, sharp and smooth images.

2. Superb performance/price ratio solution for rental market.

3. 24/7 professional after sales service, and on-site service is available.

4. Plug & Play, No tools, 10 Seconds for one panel installation / dismantle.

5. Support different shapes installation: Flat and curved ,create infinite stage styles.

6. One set cabinet structure is compatible with various pixel pitches, easily have another new screen by
changing LED module.
